Mini Vertical Wheel Repair CNC Lathe Machine
|
No. |
Item |
WRC28VM |
|
1 |
Max. swing over bed |
750mm |
|
2 |
Max. process diameter of wheel |
730mm |
|
3 |
Max. size of wheel repair |
28--32inch |
|
4 |
Chuck diameter |
320mm |
|
5 |
Spindle speed |
50-1500rpm |
|
6 |
Cutting speed |
0.1-1000mm/min |
|
7 |
Max. travel |
X/Z: 410/400mm |
|
8 |
Rapid speed |
X/Z: 8000mm/min |
|
9 |
Tool post |
Manual 4 position tool post |
|
10 |
Section of tool post |
25×25mm |
|
11 |
Feed motor power |
X/Z: 1.6kw/10Nm |
|
12 |
Linear guide nominal width |
30mm |
|
13 |
Accuracy |
0.015mm |
|
14 |
Repeatability |
0.012mm |
|
15 |
Main motor power |
7.5kw |
|
16 |
Weight |
1300kg |
|
17 |
Dimension |
1500×1820×2050mm |
